Chemical Industry and Engineering Progress ›› 2025, Vol. 44 ›› Issue (12): 7165-7175.DOI: 10.16085/j.issn.1000-6613.2024-2020
• Fine chemicals • Previous Articles
LI Ming1,2(
), SHI Xiang1,2, CUI Yongwen1,2, WANG Kai1,2, SONG Changping1,2,3, ZHANG Jiguo1,2, WANG Li1,2(
)
Received:2024-12-12
Revised:2025-01-20
Online:2026-01-06
Published:2025-12-25
Contact:
WANG Li
李明1,2(
), 史翔1,2, 崔永文1,2, 王凯1,2, 宋昌平1,2,3, 张济国1,2, 王丽1,2(
)
通讯作者:
王丽
作者简介:李明(1993—),男,硕士,研究方向为有机小分子合成。E-mail:ming.li@dyfhem.com。
基金资助:CLC Number:
LI Ming, SHI Xiang, CUI Yongwen, WANG Kai, SONG Changping, ZHANG Jiguo, WANG Li. Advances in synthesis and application of perfluoromethyl vinyl ether[J]. Chemical Industry and Engineering Progress, 2025, 44(12): 7165-7175.
李明, 史翔, 崔永文, 王凯, 宋昌平, 张济国, 王丽. 全氟甲基乙烯基醚(PMVE)的合成及应用进展[J]. 化工进展, 2025, 44(12): 7165-7175.
Add to citation manager EndNote|Ris|BibTeX
URL: https://hgjz.cip.com.cn/EN/10.16085/j.issn.1000-6613.2024-2020
| 步骤 | 产率/% |
|---|---|
| 步骤1 | 95 |
| 步骤2 | 98 |
| 步骤3 | 95.8 |
| 步骤4 | 92 |
| 步骤5 | 98.4 |
| 步骤 | 产率/% |
|---|---|
| 步骤1 | 95 |
| 步骤2 | 98 |
| 步骤3 | 95.8 |
| 步骤4 | 92 |
| 步骤5 | 98.4 |
| 参数 | 一氧化碳 | 氟气 | 三氯乙烯 | 氢氧化钠 |
|---|---|---|---|---|
| 单耗/t·t-1 | 0.22 | 0.92 | 0.65 | 0.38 |
| 单价/CNY·t-1 | 1000 | 80000 | 3500 | 2500 |
| 累计/CNY | 220 | 73470 | 2270 | 940 |
| 参数 | 一氧化碳 | 氟气 | 三氯乙烯 | 氢氧化钠 |
|---|---|---|---|---|
| 单耗/t·t-1 | 0.22 | 0.92 | 0.65 | 0.38 |
| 单价/CNY·t-1 | 1000 | 80000 | 3500 | 2500 |
| 累计/CNY | 220 | 73470 | 2270 | 940 |
| 优选催化剂 | 反应温度/℃ | 转化率/% | 选择性/% | 催化剂寿命/h |
|---|---|---|---|---|
| Ru/C | <340 | 20 | 96 | >50 |
| Pd-Cu/C | <340 | 88 | 94 | >106 |
| Pd-Sn/C | <340 | 62 | 93 | >65 |
| 优选催化剂 | 反应温度/℃ | 转化率/% | 选择性/% | 催化剂寿命/h |
|---|---|---|---|---|
| Ru/C | <340 | 20 | 96 | >50 |
| Pd-Cu/C | <340 | 88 | 94 | >106 |
| Pd-Sn/C | <340 | 62 | 93 | >65 |
| 物料 | 碳酰氟 | 六氟环氧丙烷 |
|---|---|---|
| 单耗/t·t-1 | 3.03 | 3.03 |
| 单价/CNY·t-1 | 2×104 | 8×104 |
| 累计/CNY | 6.06×104 | 2.424×105 |
| 物料 | 碳酰氟 | 六氟环氧丙烷 |
|---|---|---|
| 单耗/t·t-1 | 3.03 | 3.03 |
| 单价/CNY·t-1 | 2×104 | 8×104 |
| 累计/CNY | 6.06×104 | 2.424×105 |
| 序号 | 公司 | 产品 | 牌号 | 硬度(Shore A) | 拉伸强度/MPa | 断裂伸长率/% | 抗化学腐蚀性 | 玻璃化转变温度/℃ | 耐受温度/℃ |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 航天703所 | 7110 | 7110 | — | — | — | 除了常见溶剂,还耐N2O4 | — | -45~350 |
| 2 | 杜邦 | Kalrez/ Zalrez | 3065 | 90 | 24.10 | 17 | 芳香油/脂肪油、酸、碱、醇、醛、胺、醚、酯、蒸汽/热水 | — | 288 |
| 3 | 0040 | 70 | 8.96 | 170 | 硝酸、硫酸、冰醋酸、氢氧化铵、乙二胺、醛等的腐蚀 | -27 | -42~220 | ||
| 4 | 3M | Dyneon | 133TB | — | 16 | — | — | — | 315 |
| 5 | 大金工业公司 | Daiel per flour | DAI-EL GA-15 | 68 | 12 | 120 | — | -20 | — |
| 6 | 俄罗斯门捷列夫合成橡胶研究院 | СКΦ | 260МПАН | 72 | 11.3 | 97 | — | -47.7 | -50~300 |
| 7 | 260НТ/260ВРТ | — | — | — | — | -30 | — | ||
| 8 | 索尔维 | TECNOFLON V PFR | PFR95HT | 70 | 18.3 | 224 | 耐酸、苛性碱、酮类、醛类、酯类、醚类、甲醇、溶剂、酸性气体、碳氢化合物、蒸汽、热水腐蚀 | — | -10~300 |
| 序号 | 公司 | 产品 | 牌号 | 硬度(Shore A) | 拉伸强度/MPa | 断裂伸长率/% | 抗化学腐蚀性 | 玻璃化转变温度/℃ | 耐受温度/℃ |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 航天703所 | 7110 | 7110 | — | — | — | 除了常见溶剂,还耐N2O4 | — | -45~350 |
| 2 | 杜邦 | Kalrez/ Zalrez | 3065 | 90 | 24.10 | 17 | 芳香油/脂肪油、酸、碱、醇、醛、胺、醚、酯、蒸汽/热水 | — | 288 |
| 3 | 0040 | 70 | 8.96 | 170 | 硝酸、硫酸、冰醋酸、氢氧化铵、乙二胺、醛等的腐蚀 | -27 | -42~220 | ||
| 4 | 3M | Dyneon | 133TB | — | 16 | — | — | — | 315 |
| 5 | 大金工业公司 | Daiel per flour | DAI-EL GA-15 | 68 | 12 | 120 | — | -20 | — |
| 6 | 俄罗斯门捷列夫合成橡胶研究院 | СКΦ | 260МПАН | 72 | 11.3 | 97 | — | -47.7 | -50~300 |
| 7 | 260НТ/260ВРТ | — | — | — | — | -30 | — | ||
| 8 | 索尔维 | TECNOFLON V PFR | PFR95HT | 70 | 18.3 | 224 | 耐酸、苛性碱、酮类、醛类、酯类、醚类、甲醇、溶剂、酸性气体、碳氢化合物、蒸汽、热水腐蚀 | — | -10~300 |
| [1] | TORTELLI Vito, CALINI Pierangelo, ZOMPATORI Alberto, et al. Process for preparing fluorohalogenethers: US20070149827A1[P]. 2007-06-28. |
| [2] | DURRELL William S, STUMP Eugene C, WESTMORELAND Geraldine, et al. Polymers of fluorocarbon ethers and sulfides. I. Trifluoromethyl trifluorovinyl ether and sulfide[J]. Journal of Polymer Science A, 1965, 3(12): 4065-4074. |
| [3] | HUNG Ming-hong, ROZEN Shlomo. Production of perfluoro(alkyl vinyl ethers): US5350497[P]. 1994-09-27. |
| [4] | 杨晓勇, 周楠, 黎爽, 等. 三氟甲基- 1,1,2-三氟-1,2-二氯-乙基醚脱氯反应工艺: CN1775722A[P]. 2006-05-24. |
| YANG Xiaoyong, ZHOU Nan, LI Shuang, et al. Trifluoromethyl-1,1,2-trifluoro-1,2-dichloro-ethyl ether dechlorination process: CN1775722A[P]. 2006-05-24. | |
| [5] | MONZANI Cristiano, TORTELLI Vito. Process for the production of perfluorinated alkylvinylethers: WO2019115654A1[P]. 2019-06-20. |
| [6] | 罗凯, 窦若岸, 罗生乔, 等. 一种含氟烯醚的制备方法:CN115504869A[P]. 2022-12-23. |
| LUO Kai, DOU Ruoan, LUO Shengqiao, et al. The invention relates to a preparation method of fluoroalkenes: CN115504869A[P]. 2022-12-23. | |
| [7] | 罗凯, 罗生乔, 陈彬彬, 等. 含氟烯醚的合成方法:CN115504867A[P]. 2022-12-23. |
| LUO Kai, LUO Shengqiao, CHEN Binbin, et al. Method of synthesis of fluorolefin ether: CN115504867A[P]. 2022-12-23. | |
| [8] | 倪华, 邹学鹏, 王清, 等. 溶剂对脱氯反应制备全氟甲基乙烯基醚的影响[J]. 有机氟工业, 2023(1): 6-9. |
| NI Hua, ZOU Xuepeng, WANG Qing, et al. Effect of solvent on preparation of perfluoromethyl vinyl ether by dechlorination[J]. Organo-Fluorine Industry, 2023(1): 6-9. | |
| [9] | ANTENUCCI Emanuela, TORTELLI Vito, MILLEFANTI Stefano. Process for preparing fluorohalogenoethers: WO2019110710A1[P]. 2019-06-13. |
| [10] | 窦若岸, 陈彬彬, 罗生乔, 等. 全氟甲基乙烯基醚脱氯釜残综合利用的研究[J]. 有机氟工业, 2019(1): 9-14. |
| DOU Ruoan, CHEN Binbin, LUO Shengqiao, et al. Study on the comprehensive utilization of dechlorination residue in PMVE production process[J]. Organo-Fluorine Industry, 2019(1): 9-14. | |
| [11] | 贾文志, 朱志荣. 全氟甲基乙烯基醚合成的研究进展[J]. 化工进展, 2013, 32(10): 2480-2485. |
| JIA Wenzhi, ZHU Zhirong. Advances in synthesis of perfluoromethyl perfluorovinyl ether[J]. Chemical Industry and Engineering Progress, 2013, 32(10): 2480-2485. | |
| [12] | MILLEFANTI Stefano, TORTELLI Vito, MARCHIONNI Giuseppe. Method for manufacturing perfluorovinylethers: WO2009150091A1[P]. 2009-12-17. |
| [13] | MILLEFANTI Stefano, TORTELLI Vito, MARCHIONNI Giuseppe, et al. Method for manufacturing perfluorovinylethers: US9868684[P]. 2018-01-16. |
| [14] | GREGORI Manuel, MILLEFANTI Stefano, ALBONETTI Stefania, et al. Method for the manufacture of perfluorovinylethers: WO2018011142A1[P]. 2018-01-18 |
| [15] | GREGORI Manuel, MILLEFANTI Stefano, MARCHIONNI Giuseppe. Method for the manufacture of perfluorovinylethers: WO2018019724A1[P]. 2018-02-01. |
| [16] | SELMAN Stanley. Fluorocarbon ethers: US3274239A[P]. 1966-09-20. |
| [17] | MARTINI Thomas. Process for preparing perfluoro-alkoxy-propionic acid fluorides: US4035388A[P]. 1977-07-12. |
| [18] | CHARLES Gerhard Fritz, EARL Phillip, et al. Fluorinated vinyl ethers and their preparation: US3114778[P]. 1963-12-17. |
| [19] | GERHARD Fritz Charles, STANLEY Selman. Fluorinated vinyl ethers and their preparation: US3291843[P]. 1966-12-13 |
| [20] | EDWARD Lorenz Carl. Fluorocarbon ethers: US3321532A[P]. 1967-05-23. |
| [21] | 王军, 王汉利. 一种生产六氟环氧丙烷联产全氟乙烯基醚的方法: CN101817728A[P]. 2010-09-01. |
| WANG Jun, WANG Hanli. A method for producing perfluoroethylene oxide and co-producing hexafluoroepoxypropylene: CN101817728A[P]. 2010-09-01. | |
| [22] | 王汉利, 张琳涵, 王军. 一种高收率的全氟甲基乙烯基醚(PMVE)的绿色合成方法: CN103724167A[P]. 2014-04-16. |
| WANG Hanli, ZHANG Linhan, WANG Jun. A green synthesis method for high yield production of perfluoromethyl vinyl ether (PMVE): CN103724167A[P]. 2014-04-16. | |
| [23] | 米格尔·A·格拉. 氟化乙烯基醚的制备方法: CN101213168A[P]. 2008-07-02. |
| 米格尔·A·格拉. Preparation method of fluorinated vinyl ether: CN101213168A[P]. 2008-07-02. | |
| [24] | 周强, 王树华, 吴晓军. 一种氟化乙烯基醚的连续制备方法: CN102702035A[P]. 2012-10-03. |
| ZHOU Qiang, WANG Shuhua, WU Xiaojun. Method for continuously preparing fluorinated vinyl ether: CN102702035A[P]. 2012-10-03. | |
| [25] | 马亚锋, 齐仲龙, 杨会娥, 等. 一种流化床制备全氟甲基乙烯基醚的方法: CN107814689A[P]. 2018-03-20. |
| MA Yafeng, QI Zhonglong, YANG Hui’e, et al. Method for preparing full-fluoride methyl vinyl ether by using fluidized bed: CN107814689A[P]. 2018-03-20. | |
| [26] | BORNENGO Giorgio, PONTEVIVO Michele, MARRACCINI Antonio, et al. Process for the preparation of fluoroalkyl perfluorovinyl ethers: US4772756[P]. 1988-09-20. |
| [27] | 应良辰, 包俊, 王章明, 等. 一种制备全氟烷基乙烯基醚的反应系统及其方法: CN112552149A[P]. 2021-03-26. |
| YING Liangchen, BAO Jun, WANG Zhangming, et al. Reaction system and method for preparing perfluoroalkyl vinyl ether: CN112552149A[P]. 2021-03-26. | |
| [28] | LEE Sang Goo, Won Wook SO, PARK In Joon, et al. Method for preparing perfluoromethylvinyl ether having high conversion rate: WO2022010204A1[P]. 2022-01-13. |
| [29] | HARRIS John Ferguson J, MCCANE Donald Irwin. Fluorocarbon ethers: US3180895A[P]. 1965-04-27. |
| [30] | 张鸣, 孙凌云, 杨旭仓, 等. 一种含氟乙烯基醚的制备方法: CN101659602A[P]. 2010-03-03. |
| ZHANG Ming, SUN Lingyun, YANG Xucang, et al. Method for preparing fluorine-containing vinyl ether: CN101659602A[P]. 2010-03-03. | |
| [31] | ZHANG Ming, YANG Xucang, PENG Xiaofeng. Method for preparing fluorine-containing vinyl ether: US20140330046[P]. 2014-11-06. |
| [32] | 周晓猛, 贾晓卿, 鲍鹏. 全氟甲基乙烯基醚的制备方法: CN102211983A[P]. 2011-10-12. |
| ZHOU Xiaomeng, JIA Xiaoqing, BAO Peng. Preparation method of perfluoromethyl vinyl ether: CN102211983A[P]. 2011-10-12. | |
| [33] | 马亚锋, 杨刚, 杨会娥, 等. 一种全氟甲基乙烯基醚的制备方法: CN105367392A[P]. 2016-03-02. |
| MA Yafeng, YANG Gang, YANG Hui’e, et al. Perfluoromethyl vinyl ether preparation method: CN105367392A[P]. 2016-03-02. | |
| [34] | 马亚锋, 杨会娥, 魏攀, 等. 一种全氟甲基乙烯基醚的制备方法: CN109422628A[P]. 2019-03-05. |
| MA Yafeng, YANG Hui’e, WEI Pan, et al. Method for preparing perfluoromethyl vinyl ether: CN109422628A[P]. 2019-03-05. | |
| [35] | 罗伟棻, 邱绿洲, 丁荣文. 工业化合成全氟甲基乙烯基醚和 2-氟-1,2-二氯-三氟甲氧基乙烯的新工艺: CN114174250A[P]. 2022-03-11. |
| LUO Weifen, QIU Lyuzhou, DING Rongwen. Novel process for industrially synthesizing perfluoromethyl vinyl ether and 2-fluoro-1,2-dichloro-trifluoromethoxy ethylene: CN114174250A[P]. 2022-03-11. | |
| [36] | 崔桅龙, 罗伟棻, 邱绿洲. 工业化合成全氟甲基乙烯基醚和 1,1,2,2-四氟-1-三氟甲氧基乙烷的新工艺: CN114728873A[P]. 2022-07-08. |
| CUI Weilong, LUO Weifen, QIU Lyuzhou. Novel process for industrially synthesizing perfluoromethyl vinyl ether and 1,1,2,2-tetrafluoro-1-trifluoromethoxyethane: CN114728873A[P]. 2022-07-08. | |
| [37] | 张建新, 李斌, 兰军, 等. 各种单体对耐低温氟醚橡胶性能的影响[J]. 化工新型材料, 2011, 39(1): 122-125. |
| ZHANG Jianxin, LI Bin, LAN Jun, et al. The effect of various comonomer on character of the fluoroether rubber having resistance to low temperatures[J]. New Chemical Materials, 2011, 39(1): 122-125. | |
| [38] | 张勤来. 含有不同硫化点单体的全氟弹性体[J]. 有机氟工业, 2002(4): 55-59. |
| ZHANG Qinlai. Perfluorinated elastomers containing monomers with different vulcanization points[J]. Organo-fluorin Industry, 2002(4): 55-59. | |
| [39] | 薛丹伟, 唐京, 陈志锋. 全氟醚橡胶简介[J]. 有机氟工业, 2023(2): 34-40. |
| XUE Danwei, TANG Jing, CHEN Zhifeng. Summary of perfluoroelastomer[J]. Organo-Fluorine Industry, 2023(2): 34-40. | |
| [40] | 王婧, 韩秀峰, 廉一龙, 等. 含氟橡胶的研究进展及在航空发动机中的应用[J]. 合成橡胶工业, 2021, 44(2): 150-157. |
| WANG Jing, HAN Xiufeng, LIAN Yilong, et al. Research progress of fluorine-containing rubber and its application in aeroengine[J]. China Synthetic Rubber Industry, 2021, 44(2): 150-157. | |
| [41] | 高燕, 向宇. 全氟醚橡胶及其制品在密封行业的应用[J]. 汽车零部件, 2015(6): 59-63. |
| GAO Yan, XIANG Yu. Application of FFKM and its products in the sealing industry[J]. Automobile Parts, 2015(6): 59-63. | |
| [42] | 王兰净, 赵少春. 耐低温特种氟橡胶的合成[J]. 有机氟工业, 2012(3): 8-11. |
| WANG Lanjing, ZHAO Shaochun. Synthesis of low temperature resistant special fluororubber[J]. Organo-Fluorine Industry, 2012(3): 8-11. | |
| [43] | BOYER Cyrille, AMEDURI Bruno, HUNG Ming H. Telechelic diiodopoly(VDF-co-PMVE) copolymers by iodine transfer copolymerization of vinylidene fluoride (VDF) with perfluoromethyl vinyl ether (PMVE)[J]. Macromolecules, 2010, 43(8): 3652-3663. |
| [44] | 李恩军, 苟文亮, 李耿, 等. 一种耐低温氟橡胶组合物及其应用: CN112592548A[P]. 2021-04-02. |
| LI Enjun, GOU Wenliang, LI Geng, et al. Low-temperature-resistant fluororubber composition and application thereof: CN112592548A[P]. 2021-04-02. | |
| [45] | 尚家庄, 顾伟超, 修国华. 一种超临界二氧化碳制备全氟醚弹性体的方法: CN117362509A[P]. 2024-01-09. |
| SHANG Jiazhuang, GU Weichao, XIU Guohua. Method for preparing perfluoroether elastomer from supercritical carbon dioxide: CN117362509A[P]. 2024-01-09. | |
| [46] | 钟子强, 刘波, 余金龙, 等. 一种全氟醚橡胶及其制备方法: CN117946316A[P]. 2024-04-30. |
| ZHONG Ziqiang, LIU Bo, YU Jinlong, et al. Perfluoroether rubber and preparation method thereof: CN117946316A[P]. 2024-04-30. | |
| [47] | 赵媛媛, 白鲸, 伍永强, 等. 全氟甲基乙烯基醚(PMVE)含量对氟醚橡胶性能的影响[J]. 化工新型材料, 2015, 43(6): 94-97. |
| ZHAO Yuanyuan, BAI Jing, WU Yongqiang, et al. Effect of perfluoromethyl vinyl ether(PMVE)content on Property of fluoroether rubber[J]. New Chemical Materials, 2015, 43(6): 94-97. | |
| [48] | 余自力, 龚天龙. 四氟乙烯-全氟甲基乙烯基醚共聚物的研究进展[J]. 化工新型材料, 2012, 40(11): 12-14. |
| YU Zili, GONG Tianlong. Progress in tetrafluoroethylene-perfluoromethyl vinyl ether copolymer[J]. New Chemical Materials, 2012, 40(11): 12-14. | |
| [49] | 任伟成. 可熔性聚四氟乙烯(PFA)[J]. 有机氟工业, 2010(2): 40-44, 64. |
| REN Weicheng. Soluble polytetrafluoroethylene (PFA)[J]. Organo-Fluorine Industry, 2010(2): 40-44, 64. | |
| [50] | 袁才根, 胡春圃, 徐旭东, 等. 四氟乙烯/偏氟乙烯/全氟甲基乙烯基醚乳液共聚合反应动力学[J]. 华东理工大学学报, 2001, 27(3): 265-268, 272. |
| YUAN Caigen, HU Chunpu, XU Xudong, et al. Emulsion copolymerization kinetics of gaseous monomers containing fluorine[J]. Journal of East China University of Science and Technology, 2001, 27(3): 265-268, 272. | |
| [51] | 王飞, 刘波, 姚权卫, 等. 一种可熔性聚四氟乙烯树脂及其制备方法: CN117645682A[P]. 2024-03-05. |
| WANG Fei, LIU Bo, YAO Quanwei, et al. Fusible polytetrafluoroethylene resin and preparation method thereof: CN117645682A[P]. 2024-03-05. | |
| [52] | 邓金保. 马克西姆在美投产吡虫啉以及在以建氟酰脲装置[J]. 农药研究与应用, 2006, 10 (5): 43. |
| DENG Jinbao. Maxim is producing imidacloprid in the U.S. and has established a flufenoxuron facility in Israel[J]. Agrochemicals, 2006, 10(5): 43. | |
| [53] | 邓金保. 马克西姆的杀虫剂氟酰脲在美获临时性认可[J]. 农药研究与应用, 2007, 11 (3): 44. |
| DENG Jinbao. Maxim’s insecticide flufenoxuron has received temporary approval in the U.S.[J]. Agrochemicals Research Application[J]. Agrochemicals, 2007, 11 (3): 44. | |
| [54] | 胡笑形. 日本批准MAI的双苯氟脲[J]. 新农药, 2004(5): 40. |
| HU Xiaoxing. Japan has approved MAI’s diflubenzuron[J]. New Pesticides, 2004(5): 40. | |
| [55] | 胡笑形. 美国批准MAI的双苯氟脲[J]. 国际化工信息, 2004(11): 22. |
| HU Xiaoxing. The United States has approved MAI’s diflubenzuron[J]. Global Chemical Information, 2004(11): 22. | |
| [56] | 胡笑形. 欧盟首次批准MAI的双苯氟脲[J]. 国际化工信息, 2006(4): 22-23. |
| HU Xiaoxing. The EU has granted its first approval for MAI’s diflubenzuron[J]. Global Chemical Information, 2006(4): 22-23. | |
| [57] | 朱秋锋, 张敏卿, 陈磊. 邻氯六氟甲氧基乙氧基苯胺的合成[J]. 化工中间体, 2006(2): 18-20. |
| ZHU Qiufeng, ZHANG Minqing, CHEN Lei. The synthesis of 3-chloro-4-[1,1,2-trifluoro-2-(trifluoromethoxy)ethoxy] aniline[J]. Chemical Intermediates, 2006(2): 18-20. | |
| [58] | 周彦峰, 高中良, 邱继平, 等. 杀虫剂双苯氟脲的合成研究[J]. 河南工业大学学报(自然科学版), 2008, 29(1): 64-67. |
| ZHOU Yanfeng, GAO Zhongliang, QIU Jiping, et al. Study on synthesis of insecticide novaluron[J]. Journal of Henan University of Technology (Natural Science Edition), 2008, 29(1): 64-67. | |
| [59] | 周彦峰, 高中良, 邱继平, 等. 3-氯-4-[1,1,2-三氟-2-(三氟甲氧基)乙氧基]苯胺的合成研究[J]. 应用化工, 2007, 36(12): 1249-1251. |
| ZHOU Yanfeng, GAO Zhongliang, QIU Jiping, et al. Study on synthesis of 3-chloro-4-[1,1,2-trifluoro-2-(trifluoromethoxy)-ethoxy] aniline[J]. Applied Chemical Industry, 2007, 36(12): 1249-1251. | |
| [60] | 周彦峰, 高中良, 邱继平, 等. 几丁质抑制杀虫剂双苯氟脲的合成研究[J]. 化工中间体, 2007(10): 12-14. |
| ZHOU Yanfeng, GAO Zhongliang, QIU Jiping, et al. Study on synthesis of insecticide novaluron one kind of benzoylureas[J]. Chemical Intermediates, 2007(10): 12-14. | |
| [61] | OHATA Satoru, KATO Katsuya, TORIYABE Keiji, et al. 3-烷氧基-1 -苯基吡唑衍生物及有害生物防除剂: CN101821239A[P]. 2010-09-01. |
| OHATA Satoru, KATO Katsuya, TORIYABE Keiji, et al. 3-alkoxy-1-phenylpyrazole derivatives and pest control agents: CN101821239A[P]. 2010-09-01. | |
| [62] | KINPARA Akira, ISHIKAWA Ryo, TORIYABE Keiji, et al. Pyrazole-3-carboxylic acid amide derivative and pest control agent: US11993578[P]. 2024-05-28. |
| [63] | PAZENOK Sergii, VORS Jean-Pierre, LEROUX Frédéric R, et al. Process for preparing substituted pyrazoles containing haloalkoxy- and haloalkylthio groups from α,α-dihaloalkylamines and ketimines: WO2016207167A1[P]. 2016-12-29. |
| [64] | PETKO Kirill I, FILATOV Andrey A. Addition reaction of various azoles to perfluoromethyl vinyl ether[J]. Chemistry of Heterocyclic Compounds, 2021, 57(6): 666-671. |
| [65] | SCHMITT Etienne, BOUVET Sébastien, Bruce PÉGOT, et al. Fluoroalkyl amino reagents for the introduction of the fluoro(trifluoromethoxy)methyl group onto arenes and heterocycles[J]. Organic Letters, 2017, 19(18): 4960-4963. |
| [66] | ARIBI Fallia, PANOSSIAN Armen, VORS Jean-Pierre, et al. 2,4-Bis(fluoroalkyl)quinoline-3-carboxylates as tools for the development of potential agrochemical ingredients[J]. European Journal of Organic Chemistry, 2018, 2018(27/28): 3792-3802. |
| [67] | 卢伟, 赵鹏. N-[3-氯-4-(1,1,2-三氟-2-三氟甲氧基-乙基)-苯基]-2,6 -二氟-苯甲眯、制备方法与应用: CN110746322A[P]. 2020-02-04. |
| LU Wei, ZHAO Peng. N-[3-chloro-4-(1,1,2-trifluoro-2-trifluoromethoxyethyl)phenyl]-2,6 -difluorobenzamide, preparation method, and application: CN110746322A[P]. 2020-02-04. | |
| [68] | 曲文岩, 郭峰. 具有杀虫、杀螨活性的醚衍生物及其制备方法与应用: CN116178249A[P]. 2023-05-30. |
| QU Wenyan, GUO Feng. Ether derivative with insecticidal and acaricidal activity and preparation method and application thereof: CN116178249A[P]. 2023-05-30. | |
| [69] | MANGIN Loïc P, PORTO Luana L T N, OVENS Jeffrey S, et al. Synthesis and reactivity of functionalized fluoro-nickelacyclopentanes[J]. Organometallics, 2024, 43(3): 308-321. |
| [70] | TVERDOMED Sergey N, HIRSCHBERG Markus E, PAJKERT Romana, et al. Interaction of O- and P- nucleophiles with perfluorinated olefins: Novel synthetic route to fluorinated phosphorus-containing monomers[J]. Journal of Fluorine Chemistry, 2023(269): 110152-110169. |
| [71] | PETROV Viacheslav A, KRESPAN Carl G. Conjugate electrophilic iodofluorination of fluoroolefins[J]. The Journal of Organic Chemistry, 1996, 61(26): 9605-9607. |
| [72] | SONG Ki Dong, Yeon Ho OH, JANG Hyun Jae, et al. Insulating gas used for electrical insulation or arc extinguishing by replacing SF6 gas and electrical device using same: US20240194372[P]. 2024-06-13. |
| [73] | SINHA Nidhi, CHOI Heechol, SONG Mi-Young, et al. Perfluoro-methyl-vinyl-ether as SF6 alternative in insulation applications: A DFT study on the physiochemical properties and decomposition pathways[J]. Computational and Theoretical Chemistry, 2023, 1225: 114159. |
| [74] | XIAO Song, CHEN Yijiang, TANG Mingjun, et al. Characteristics of perfluoromethyl vinyl ether: A new eco-friendly alternative gas for SF6 [J]. High Voltage, 2024, 9(3): 509-517. |
| [1] | LI Yanping, YANG Tao, WANG Hongxun, ZHANG Cheng, WEN Guosheng, HAN Zhicheng, LAN Gongjia, YAN Dazhou. Reaction molecular dynamics simulation of the thermal decomposition and reduction system of trichlorosilane in a hydrogen atmosphere [J]. Chemical Industry and Engineering Progress, 2025, 44(8): 4322-4330. |
| [2] | HAN Yuandi, ZOU Yun, LIANG Zhichao, TONG Zhangfa, CHEN Xiaopeng, LIAO Dankui. Preparation of high-temperature potassium bicarbonate foaming agent and its application in polypropylene microfoaming materials [J]. Chemical Industry and Engineering Progress, 2025, 44(3): 1599-1606. |
| [3] | ZHANG Hao, LU Xiaoming. Thermal decomposition kinetics and particle evolution characteristics of nano barium titanate precursor [J]. Chemical Industry and Engineering Progress, 2024, 43(7): 3987-3995. |
| [4] | ZHAO Peitao, FU Binbin, ZHAO Quan, ZUO Wu, ZHOU Haiyun, HAN Dongtai. Thermal decomposition of plastics via low pressure and superheated solvent steam and its characteristics [J]. Chemical Industry and Engineering Progress, 2024, 43(6): 3420-3429. |
| [5] | XU Ming, SHAO Mingfei, LIU Qingya, DUAN Xue. Hydrogen generation from electrochemical water splitting coupling carbonate reduction [J]. Chemical Industry and Engineering Progress, 2022, 41(3): 1121-1124. |
| [6] | Xiaojuan LAI,Yinyin ZHANG,Jiahui LIU,Lei WANG. Preparation and properties of surface modified GO modified amine-free waterborne polyurethane-acrylate emulsion [J]. Chemical Industry and Engineering Progress, 2020, 39(4): 1389-1395. |
| [7] | Kai YE, Feng LIANG, Yaochun YAO, Wenhui MA, Bin YANG, Yongnian DAI. Development trend of preparation and application of nickel nano-powder [J]. Chemical Industry and Engineering Progress, 2019, 38(05): 2252-2261. |
| [8] | ZHENG Xiarong, LI Yongxiang, WANG Jianlong, CAO Duanlin, WANG Yanhong, CHENG Xiaoyan. Synthesis and characterization of nonanitroterphenyl [J]. Chemical Industry and Engineering Progree, 2015, 34(3): 820-824. |
| [9] | CAO Xianwu,ZHANG Yijun,WU Wei,WU Pengjun. Thermal analysis of modified sodium bicarbonate [J]. Chemical Industry and Engineering Progree, 2012, 31(10): 2176-2182. |
| [10] | LENG Jibin,YU Zhaoyang,LI Zhenhu,ZENG Dong,DAI Wei,GUO Kai. Exploratory study on hydrogen sulfide removal from natural gas in a rotating packed bed (RPB) by oxidation reduction method [J]. Chemical Industry and Engineering Progree, 2007, 26(7): 1023-. |
| [11] | HU Zhiyong,CHENG Yuan,LI Lei,ZHANG Qiaoling. New method for synthesizing azobis(isobutylamidine hydrochloride) [J]. Chemical Industry and Engineering Progree, 2007, 26(12): 1790-. |
| [12] | MA Hongting,ZHANG Yufeng,DENG Na,GUO Xiaojuan,WEI Lili. Main factors influencing the thermal decomposition characteristics of medical waste [J]. Chemical Industry and Engineering Progree, 2007, 26(12): 1783-. |
| Viewed | ||||||
|
Full text |
|
|||||
|
Abstract |
|
|||||
|
京ICP备12046843号-2;京公网安备 11010102001994号 Copyright © Chemical Industry and Engineering Progress, All Rights Reserved. E-mail: hgjz@cip.com.cn Powered by Beijing Magtech Co. Ltd |
